1. Refine the input files without flattening, including the following
options:
a. In the
Normalize
section of the refine process template, in the
PDF 1.4-1.6 (Acrobat 5-7)
box, select
Leave as is
.
b. Perform all operations such as trapping and Color Matching on
the unflattened file.
2. Once the pages are ready to send out, set the job to use APPE.
a. In the
Edit
menu of Job Manager, select
Edit Job Attributes
.
b. In the
Edit Job Attributes
dialog box, in the
RIP Name
box,
select
Adobe PDF Print Engine
.
3. Output to PDF raster.
a. Start an output process.
b. In the
Output To
box at the top of the process template, select
PDF Raster
.
c. Set options in the
Render
section as desired.
For example, output to 600 dpi, 256 shades with antialiasing set
to 2.
The result is a raster PDF that you use as the exchange file. The file will
contain contone data, and will be large and uneditable. Nevertheless,
the file will print correctly regardless of the downstream RIP.
Page set booklets
About page set booklets
Page set booklets are two-sided proofs of pages in reader order that
can be printed on a duplexing laser printer.
You generate this type of proof after assigning pages to page positions.
The purpose of the page set booklet is to ensure that the pages are
correctly assigned.
The order in which you select the pages is the order Prinergy uses
when creating a saddle-stitched imposition. You can either sort the
pages in the desired order then select them, or press the command key
(Mac) or CTRL key (PC) while selecting individual pages in the order
you want.
Note: If you selected pages then changed the sort order, the sort order of the
selected pages changes to match the new sort order. To maintain the selected sort
order while you sort pages (for example, if you're looking for another page to
select), press the Shift key while you're sorting.
Page set booklets are also called saddle-stiched imposition output or
feel-good books.
