Output Comment
Use this box to type a comment associated with the output, if
desired. This box defaults to the last output comment that you
entered on this workstation.
The comment is stored in the
History
view for the job.
You can also place this text on output using the variable mark
$
[OutputComment]
in page or sheet marks.
Selected Items
Expand this section to view a list of the jobs or elements
selected for processing.
Layered PDF Flattening Warning
When you process layered PDF files, a warning message
appears to indicate that if the
PDF 1.4-1.6 (Acrobat 5-7)
option
located in the
Normalize
section of the refine process template
is set to
Flatten to PDF 1.3
, the refined files will be flattened and
layers will be combined as indicated in the Layer Selection
dialog box.
Layer handling happens before flattening, so that layers are
handled as specified in the Layer Selection dialog box before
flattening occurs. This allows you to omit certain layers before
processing the page as PDF 1.3. As a general rule, for Layered
PDF Versioning (LPV) jobs, you do not want to flatten to PDF
1.3, which would destroy the layers of the incoming PDF 1.5 file.
This would defeat the purpose of using layered input.
Note: If you use Rules-Based Automation to start a process, most options in the
dialog box do not apply, so they are not displayed.
Start Process for Digital Printing dialog box
Digital Device Queue
Displays the name of the selected queue on the digital device.
Process Name
Displays information about the process you are submitting to
the digital device. By default, information is displayed in the
following format:
<digital device>:<print settings>:<number of pages being
processed>
However, you can rename the process as desired.
Start Process for Digital Printing dialog box
