If the pages are assigned to page positions linked to an
imposition plan, this value is added to the bounding box defined
on the imposition plan. If the assigned page positions are linked
to multiple imposition plans, the largest bounding box is
calculated and this value is added to the calculated
measurement.
Default Marks Font
Prinergy can populate variable marks with double-byte
characters such as those found in Japanese, Chinese, and
Korean.
Here's an example of how you could use the feature:
1. Create a Preps imposition file that includes a variable mark,
such as
$[PageName]
.
2. In Prinergy, in the
Default Marks Font
box in the
Marks
section of the imposition output process template, type the
exact name of the double-byte font that can be used in case
the variable mark's original font was not a double-byte font.
The font must reside either in a Prinergy-aware font folder or
in the job's font search path.
3. Submit the imposition file to Prinergy.
If the imposition file contains a page name with double-byte
fonts, Prinergy outputs the file with these characters.
Sheet Marks
Identify the name and location of a PDF file containing sheet
marks (for example variable marks, logo, and signoff line). Click
Browse
to locate and select a file.
Calibrate
When this check box is selected, the plate curve and print curve
are applied to the mark. The curves applied are the ones
selected in the
Plate Curve
list and
Print Curve
list in the
Calibration and Screening
section of the process template.
When this check box is cleared, only the plate curve is applied.
To prevent the application of the plate curve to a mark, select
%
%None%%
in the
Plate Curve
list in the
Calibration and
Screening
section of the process template.
Locate Sheet Marks Adjacent to
(See
on page
and
on page
)
Select
Left
,
Right
,
Bottom
, or
Top
to determine on which edge
of the paper or plate a sheet mark is placed.
484
Chapter 12—Outputs
