Device Type
Type the type and version of the digital printer to assist Xerox
FreeFlow Print Manager in translating the JDF. For example,
type
DC8000_SPIRE1.0
.
Protocol
Type the name of the print protocol that the digital printer uses.
Xerox FreeFlow Print Manager translates the JDF into this print
protocol. For example, type
SPIREPR
.
Job Spec
Type the name of a pre-defined workflow.
This box applies only when you have selected an HP device.
Marks section in the Loose Page Output process template
This process template section determines how marks are handled
during loose page output.
Extra Margin for Marks and Bleed
When calculating the position of pages, additional space is
included for marks and the bleed, if indicated.
Provide margin values for
Left
,
Right
,
Top
, and
Bottom
margins,
in the selected unit of measure.
Bleed for Unassigned Pages
Prints a bleed line when proofing PDF pages that have not yet
been assigned to a position of an imposition plan. When
assigned pages are proofed, the bleed lines are taken from the
imposition plan.
Provide values for
Left
,
Right
,
Top
, and
Bottom
in the selected
unit of measure.
Crop Distance Beyond Bleed for Pages
Creates an additional margin beyond the bleed marks to allow
output of the software information that is positioned outside
the bleed.
Provide values for
Left
,
Right
,
Top
, and
Bottom
, in the selected
unit of measure.
This value, and any value that extends the crop beyond the page
size, allows the entire page image to be output (up to the page
size defined by other layout measurements).
A negative value moves the crop inside the bleed by the
specified amount.
Marks section in the Loose Page Output process template
