in Prinergy means that you do not have to set up registration
parameters each time you load a plate.
Media registrations, which are set up for specific presses and
can apply to a single plate size or a range of plate sizes, are
created in Print Console.
Name
Available when a vendor's device has been defined through the
Prinergy Administrator. Available options are determined by the
device.
Size
Determines the size of the media to which you will output the
final files.
Select
Digital
to generate an output file, for example, a file for
Virtual Proofing System software. When you select
Digital
, the
Min Width
,
Min Height
,
Max Width
,
Max Height
, and
Layout is
90° Different Than Media
boxes are unavailable.
Select
Cut sheet
,
Roll fed
, or
Roll fed (transverse)
, depending
on the media being used.
Min Width
Sets the minimum width for the specified media in the unit of
measure selected in the list.
Min Height
Sets the minimum height for the specified media in the unit of
measure selected in the list.
For cut sheet, enter the sheet height. For roll fed, enter the
height of the smallest proof you want to make on the device.
Max Width
Sets the maximum width for the specified media in the unit of
measure selected in the list.
Max Height
Sets the maximum height for the specified media in the unit of
measure selected in the list.
Duplexing
This option is available for composite files; it is unavailable for
separated files.
Specifies the type of duplexing.
Final Output process template
557
