Virtual Versioned Page One
as defined in Version Plan
Generated
Versioned
Page One
One layered PDF file
GENERATE
Common
Eng East
Eng West
Esp East
Esp West
RC_EngEast.p1.pdf
RC_EngEast.p2.pdf
RC_EngEast.p3.pdf
RC_EngWest.p1.pdf
RC_EngWest.p2.pdf
RC_EngWest.p3.pdf
RC_EspEast.p1.pdf
RC_EspEast.p2.pdf
RC_EspEast.p3.pdf
RC_EspWest.p1.pdf
RC_EspWest.p2.pdf
RC_EspWest.p3.pdf
Refined pages
linked to layers
Colors to
extract
Layer
RC_EngEast.p1.pdf
RC_EngEast.p1.pdf
RC_EngWest.p1.pdf
RC_EspEast.p1.pdf
RC_EspWest.p1.pdf
CMYK
K
K
K
K
Common
EngEast
EngWest
EspEast
EspWest
Model 3 scenario
In this model 3 example, your version plan is the same as in model 1.
Using input file model 3, your refined pages for versioned page one of
the nationwide catalog would be:
CcMcYcKc
+S
1
S
1
S
1
versions 1, 2, 3
Building versioned pages in model 3
Using model 3, all base and change content for a versioned page are in
one refined page. Therefore, link the refined pages to all layers
including the common layer because a refined page contributes to all
layers.
Tip: To link to all layers at one time, use the Link to Layers dialog box, and select
the
All layers
option to link a set of refined pages to all layers.
The following figure shows the refined pages to link to versioned page
one.
Model 3 scenario
