Provide values for
Left
,
Right
,
Top
, and
Bottom
in the selected
unit of measure.
Crop Distance Beyond Bleed for Pages
Creates an additional margin beyond the bleed marks to allow
output of the software information that is positioned outside
the bleed.
Provide values for
Left
,
Right
,
Top
, and
Bottom
, in the selected
unit of measure.
This value, and any value that extends the crop beyond the page
size, allows the entire page image to be output (up to the page
size defined by other layout measurements).
A negative value moves the crop inside the bleed by the
specified amount.
If the pages are assigned to page positions linked to an
imposition plan, this value is added to the bounding box defined
on the imposition plan. If the assigned page positions are linked
to multiple imposition plans, the largest bounding box is
calculated and this value is added to the calculated
measurement.
Default Marks Font
Here's an example of how you could use the feature:
1. Create a Preps imposition file that includes a variable mark,
such as
$[PageName]
.
2. In Prinergy, in the
Default Marks Font
box in the
Marks
section of the imposition output process template, type the
exact name of the double-byte font that can be used in case
the variable mark's original font was not a double-byte font.
The font must reside either in a Prinergy-aware font folder or
in the job's font search path.
3. Submit the imposition file to Prinergy.
If the imposition file contains a page name with double-byte
fonts, Prinergy outputs the file with these characters.
Sheet Marks
Identify the name and location of a PDF file containing sheet
marks (for example variable marks, logo, and signoff line). Click
Browse
to locate and select a file.
Calibrate
When this check box is selected, the plate curve and print curve
are applied to the mark. The curves applied are the ones
CTLW Karat Output process template
615
