NewLW
: Renders LW to the Kodak extended LW format.
This format supports up to 32 separations CMYK and up to
64,000 colors.
Note: A New LW file is given an
.nlw
extension.
Make CT same size as Linework file
Select to insert 1-pixel DeviceCMYK CT images in the upper-
left and lower-right corners of the media box on PDF pages. The
resulting CT layer:
●
Is the same size as the LW layer
●
Has all DeviceCMYK process colorants
This check box is available only when:
●
Output To
at the top of the process template is set to
CT/
LW (CTLWOutput)
.
●
Output Kind
in the
CT/LW
area of the
Render
section is set
to
TIFF/IT Job Only
or
CT/LW and TIFF/IT Jobs
.
TIFF/IT Suffix
TIFF/IT FP
When outputting to TIFF/IT, specify the file name ending for
the final page (FP) file. Type the file name suffix, which can
include characters before the extension—for example,
_FP.tif
.
TIFF/IT CT
When outputting to TIFF/IT, specify the file name ending for
the continuous tone (CT) file. Type the file name suffix, which
can include characters before the extension—for example,
_CT.tif
.
TIFF/IT LW
When outputting to TIFF/IT, specify the file name ending for
the line work (LW) file. Type the file name suffix, which can
include characters before the extension—for example,
_LW.tif
.
TIFF/IT HC
When outputting to TIFF/IT, specify the file name ending for
the high-resolution contone (HC) file. Type the file name suffix,
