To output refined pages with no color setup assigned to them,
you can select the
Allow undefined color setup or color setup
mismatch
setting.
The list of devices and device conditions is unfiltered when
<Job_Color_Setup>
is selected. Note that this may cause
output to fail, if the device and device condition selected are not
in the job color setup. A message will be logged in the process
history, and you will need to either select a device and device
condition used in the job color setup or use the recommended
solution, as described above.
When
<Color_Setup_Assigned_by_Refine>
is selected, the list
of devices and device conditions is also unfiltered, and the
Allow undefined color setup or color setup mismatch
check
box is grayed out and cannot be used. Note that this is the
default color setup setting for all process templates that were
upgraded from Prinergy Connect 5.1.
Device
An individual occurrence of a physical device that captures or
produces an image. Devices have a type and customer-
specified properties, such as a name and location in the plant.
Because the declaration of a device does not include its
operating conditions—such as ink selection, type of screening,
and paper—you cannot measure the color response of a device
on its own.
When a process template is configured for halftone (screened)
output processes, this list displays the names of all curved
devices used in PCO (primary color output) or SCO (secondary
color output) device conditions in the selected color setup and
snapshot. Curved print devices are those with the following
device types:
●
Offset press—for example, sheetfed, heatset web, coldset
web
●
Digital press—for example, Versamark
●
Digital halftone proofer—for example, Kodak Approval,
Trendsetter Spectrum
When a process template is configured for continuous-tone
(non-screened) output, this list displays the names of all non-
curved devices used in PCO or SCO device conditions in the
selected color setup and snapshot. Non-curved devices are
those with the following device types:
