Minimum Dot Size
Type the lowest tint percentage, with up to one decimal place,
at which dots will be imaged—for example, 10% or 10.5%. This
feature is available only if you specified a plate or print curve.
You can use this feature to remove scum dots on flexo plates.
Screening Mode
(See also the topic about document screening in this guide.)
●
Select
Override all Screening
to use the screening specified
in the process template. This option ignores any screening
specified in the source PDF file or the Prinergy DotShop
software.
●
Select
Keep DotShop Settings
to use the screening specified
in the DotShop software, when available. For pages that are
not modified in DotShop, the screening specified in the
process template is used.
●
Select
Use Document's Screening, if Present
to use the
screening specified in the source PDF file.
This option also uses the screening specified in DotShop,
when available. For pages containing no screening
information, the screening specified in the process template
is used.
You can use one or more of the
Angles
,
Frequencies
, and
Dot Shapes
settings specified on the page and allow the
process template to determine the parameters that you did
not specify.
Note: If Prinergy does not support the screen angles in the source PDF
file, the nearest supported angle is used.
Note: This option offers the greatest risk of poor results, because screen
angles identified in the source PDF file may not be suitable for the output
device.
Screen Type and Screen System
(See also the topics about screen types and screen systems.)
Screen Type
lists the following default screening information:
Imposition Output process template
