NexPress press’s page format specifications for international paper sizes:
Keys to a clean finish.
Printable area
Note when printing on a Kodak
NexPress digital production color
press, the printable area on every size
sheet is bounded by a nonprinting
area around the edges of the sheet.
These margins need to be calculated
into the final layout of any document.
An easy way to design for this is to
allow at least 6 mm (.25 inch) non-
printing margin around the entire final
layout, front and back. Make sure all
bleeds, notes and production marks
are inside this margin. The chart below
shows the maximum printing area for
standard sheet sizes often printed on
a NexPress press.
Format
Metric (mm)
Printable area
Inches
Printable area
A4
210 x 297
199 x 286
8.25 x 11.75 7.86 x 11.34
A4 Extra
235 x 322
224 x 311
9.25 x 12.67 8.86 x 12.26
A3
297 x 420
286 x 409
11.69 x 16.54 11.30 x 16.13
A3 Extra
356 x 520
340 x 510
14 x 20.47
13.4 x 20
Format
Metric (mm)
Printable area
Inches
Printable area
Letter
216 x 279
205 x 268
8.5 x 11
8.11 x 10.59
Letter Extra
242 x 305
231 x 294
9.5 x 12
9.11 x 11.59
Max Page
350 x 405
339 x 394
13.8 x 17.7 13.41 x 17.29
Tabloid
279 x 432
268 x 421
11 x 17
10.61 x 16.59
Tabloid Extra
305 x 457
294 x 446
12 x 18
11.61 x 17.59
NexPress press’s page format specifications for U.S. paper sizes:
Paper and substrates
The NexPress press provides excellent
results and true color reproduction on a
wide assortment of paper types includ-
ing coated, uncoated, gloss, matte and
textured finishes. It handles weights
from 20# (80 g/m
2
) bond to 110#
(300 g/m
2
) cover and label stocks.
Bleeds
Prepare jobs that bleed in exactly the
same way as you would for conven-
tional printing with an extra 3 mm
(.125 inch) to allow for trimming on
the bleed edges. For die cut jobs, you
may want to increase your bleed to 6
mm (.25 inch) to anticipate possible
movement on finishing devices.
